FST800-211 High Accurate 0-5vdc 20 bar 500 bar 100 psi Pressure Sensor waterproof
Product advantages:
♦ Advance Microfused Silicon Strain Gauge, whole-designed elastomer, free of leakage troubles.
♦ Efficient lightning protection and strong anti RFI&EMI protection.
♦ Advanced digital temperature compensation and wide working temperature scope.
♦ High sensibility, high accuracy, high frequency response and longterm stability.
Application:
♦ Industrial process testing and control.
♦ Automatic testing system.
♦ Hydraulic and pneumatic systems.
♦ Pump station and water treatment system.
♦ Industrial machinery manufacture.
Product parameters:
Dimensions and electrical connections:
![FST800-211 High Accurate 0-5VDC 20 bar 500 bar 100 psi Pressure Sensor waterproof](https://img3.grofrom.com/wxzktemptrsmt/d7cd1a40e2d62bb0f443524dc7e54afa.webp)
![FST800-211 High Accurate 0-5VDC 20 bar 500 bar 100 psi Pressure Sensor waterproof](https://img3.grofrom.com/wxzktemptrsmt/7c36194113c240f040373e97941d0119.webp)
![FST800-211 High Accurate 0-5VDC 20 bar 500 bar 100 psi Pressure Sensor waterproof](https://img3.grofrom.com/wxzktemptrsmt/10d75e308314010724841f89fa0f36e7.webp)
Circuit wiring diagram:
![FST800-211 High Accurate 0-5VDC 20 bar 500 bar 100 psi Pressure Sensor waterproof](https://img3.grofrom.com/wxzktemptrsmt/1acebce0931910f1ebd91581c4fe4144.webp)
Product details display:![FST800-211 High Accurate 0-5VDC 20 bar 500 bar 100 psi Pressure Sensor waterproof](https://img3.grofrom.com/wxzktemptrsmt/3b8f00f835b2db0d606571eb20ea1d4f.webp)
Why Choose Our Firstrate?![FST800-211 High Accurate 0-5VDC 20 bar 500 bar 100 psi Pressure Sensor waterproof](https://img3.grofrom.com/wxzktemptrsmt/de73be066b5d34831d5ad5389ed0f631.webp)
![FST800-211 High Accurate 0-5VDC 20 bar 500 bar 100 psi Pressure Sensor waterproof](https://img3.grofrom.com/wxzktemptrsmt/feca63d01b14cb5ee16f6d4b286848d9.webp)
![FST800-211 High Accurate 0-5VDC 20 bar 500 bar 100 psi Pressure Sensor waterproof](https://img3.grofrom.com/wxzktemptrsmt/8efcadbc4f5f0163c6eb475b546a46b0.webp)
♦ Focus on sensor production for more than 50 years;
♦ Factory Outlet, Low price;
♦ 12 months free repaire warranty;
♦ Firstrate products have past CE, ROHS, ISO9001 etc.
Contact us:
Product advantages:
♦ Advance Microfused Silicon Strain Gauge, whole-designed elastomer, free of leakage troubles.
♦ Efficient lightning protection and strong anti RFI&EMI protection.
♦ Advanced digital temperature compensation and wide working temperature scope.
♦ High sensibility, high accuracy, high frequency response and longterm stability.
Application:
♦ Industrial process testing and control.
♦ Automatic testing system.
♦ Hydraulic and pneumatic systems.
♦ Pump station and water treatment system.
♦ Industrial machinery manufacture.
Product parameters:
Standard Range | |
Pressure Type: gauge pressure absolute pressure sealed pressure | |
Pressure Range(bar):1 1.6 2.5 4 6 10 16 25 40 60 100 160 200 250 300 400 500 600 | |
Pressure Range(psi):15 30 50 75 100 200 300 500 750 1K 1.5K 3K 5K 10K | |
Technical Index | |
Signal output | 4~20mA 0.5~4.5VDC 0~5VDC 0~10VDC |
Signal line specification | 2wire 3wire 3wire 3wire |
Power Voltage | 9~30VDC 5VDC 9~30VDC 15~30VDC |
Accuracy | ±0.1%FS ±0.3%FS ±0.5%FS |
Zero Drift | ±0.02%FS/°C |
Thermal Sensitivity Shift | ±0.02%FS/°C |
Longterm Stability (1 Year) | ±0.1%FS |
Frequency Response (-3dB) | 3.2kHz |
Compensated Temperature | -20~+85°C |
Working Temperature | -40~+125°C |
Storage Temperature | -40~+125°C |
Overload Pressure | 300% FS |
Burst Pressure | 500% FS |
Mechanical Vibration | ±20g |
Impact (11ms) | 100g |
Environmental Protection | IP65 |
Housing Parts | 17-4PH |
Electromagnetic compatibility | EN61000-6 |
Certificates | CE RoHS |
Dimensions and electrical connections:
![FST800-211 High Accurate 0-5VDC 20 bar 500 bar 100 psi Pressure Sensor waterproof](https://img3.grofrom.com/wxzktemptrsmt/d7cd1a40e2d62bb0f443524dc7e54afa.webp)
![FST800-211 High Accurate 0-5VDC 20 bar 500 bar 100 psi Pressure Sensor waterproof](https://img3.grofrom.com/wxzktemptrsmt/7c36194113c240f040373e97941d0119.webp)
![FST800-211 High Accurate 0-5VDC 20 bar 500 bar 100 psi Pressure Sensor waterproof](https://img3.grofrom.com/wxzktemptrsmt/10d75e308314010724841f89fa0f36e7.webp)
Circuit wiring diagram:
![FST800-211 High Accurate 0-5VDC 20 bar 500 bar 100 psi Pressure Sensor waterproof](https://img3.grofrom.com/wxzktemptrsmt/1acebce0931910f1ebd91581c4fe4144.webp)
Product details display:
![FST800-211 High Accurate 0-5VDC 20 bar 500 bar 100 psi Pressure Sensor waterproof](https://img3.grofrom.com/wxzktemptrsmt/3b8f00f835b2db0d606571eb20ea1d4f.webp)
Why Choose Our Firstrate?
![FST800-211 High Accurate 0-5VDC 20 bar 500 bar 100 psi Pressure Sensor waterproof](https://img3.grofrom.com/wxzktemptrsmt/de73be066b5d34831d5ad5389ed0f631.webp)
![FST800-211 High Accurate 0-5VDC 20 bar 500 bar 100 psi Pressure Sensor waterproof](https://img3.grofrom.com/wxzktemptrsmt/feca63d01b14cb5ee16f6d4b286848d9.webp)
![FST800-211 High Accurate 0-5VDC 20 bar 500 bar 100 psi Pressure Sensor waterproof](https://img3.grofrom.com/wxzktemptrsmt/8efcadbc4f5f0163c6eb475b546a46b0.webp)
♦ Focus on sensor production for more than 50 years;
♦ Factory Outlet, Low price;
♦ 12 months free repaire warranty;
♦ Firstrate products have past CE, ROHS, ISO9001 etc.
